Design of the Microstrip Meander Line Antenna

Oct 13, 2025 by ludoplayers7.com 24 views

Design and Analysis of the Meander Line Microstrip Antenna for the RFID Reader Application (915 MHz)

Introduction

RFID technology (Radio Frequency Identification) has become one of the most significant innovations in various fields, ranging from inventory management to process automation and access management. The increasing demand for efficient and reliable data transfer has led to the development of advanced RFID systems. In this context, the Microstrip Meander Line antenna is specifically designed to operate at a frequency of 915 MHz, which is expected to provide optimal performance. The design process is carried out using the 2019 CST application simulation, which facilitates the analysis and optimization of various antenna parameters.

Design of the Microstrip Meander Line Antenna

The design of the Microstrip Meander Line antenna involves a number of important parameters that must be considered, such as the dimensions of the antenna, the width of the line, the distance between the lines, and the size of the ground plane. With the right settings, it is expected that the antenna can achieve the desired performance characteristics, including a good return loss and VSWR (Voltage Standing Wave Ratio). The return loss is a measure of the amount of power reflected back to the source, while the VSWR is a measure of the impedance mismatch between the antenna and the transmission line.

In the initial simulation, the results show that the antenna loss return value reached -6.096 dB and VSWR of 2.965. The negative return loss value indicates a portion of the reflected power, which means that the antenna is not fully efficient in emitting waves. On the other hand, a high VSWR value indicates a lack of impedance, so further optimization needs to be done. This highlights the importance of optimizing the antenna design to achieve better performance.

Antenna Optimization

After the initial analysis, the next step is to optimize the antenna design. This process involves changing several design parameters to improve the performance of the antenna. The results of the optimization simulation showed significant improvements to the return loss reaching -29,317 dB and VSWR which decreased to 1,071. These results indicate that the optimized Meander Line microstrip antenna has better efficiency in emitting and receiving signals at a frequency of 915 MHz.

The lower return loss value indicates that less power is reflected again, so that more power can be used for effective communication. This is a significant improvement over the initial results, demonstrating the effectiveness of the optimization technique. The optimized antenna design is expected to provide better performance in various RFID applications, ensuring reliable and efficient data transfer.

Parametric Analysis

To further analyze the performance of the optimized antenna, a parametric analysis was conducted. This involved varying the dimensions of the antenna, such as the width of the line and the distance between the lines, to study their effect on the return loss and VSWR. The results of the parametric analysis showed that the optimized antenna design is sensitive to changes in the dimensions of the antenna.

For example, increasing the width of the line by 10% resulted in a significant improvement in the return loss, while decreasing the distance between the lines by 20% resulted in a slight improvement in the VSWR. These results highlight the importance of carefully designing the antenna to achieve optimal performance.

Conclusion

From the design and analysis of the Microstrip Meander Line antenna for the RFID reader application at a frequency of 915 MHz, it is proven that the right optimization technique can significantly improve the performance of the antenna. With a better return loss and VSWR, this antenna is expected to provide effective solutions to various RFID applications, ensuring reliable and efficient data transfer.

The development of RFID technology has led to the need for advanced antenna designs that can provide optimal performance. The optimized Meander Line microstrip antenna is a significant step towards achieving this goal. With the increasing demand for efficient and reliable data transfer, this antenna design is expected to play a crucial role in the development of more sophisticated and effective RFID systems in the future.

Future Work

Future work on this project can involve further optimization of the antenna design to achieve even better performance. This can be done by using advanced optimization techniques, such as genetic algorithms or particle swarm optimization, to find the optimal design parameters. Additionally, the antenna design can be modified to operate at different frequencies, such as 2.4 GHz or 5.8 GHz, to provide a more versatile solution for various RFID applications.
