Emitted Electric Noise from Electroluminescent Display of a Mixing Console: A Troubleshooting Guide

As an audio enthusiast, owning a vintage mixing console can be a dream come true. However, when it starts to malfunction, it can be a nightmare. In this article, we will discuss a common issue faced by owners of old mixing consoles, specifically the Acousta DCA-200 from the 90s. The problem is related to the electroluminescent display (ELD) emitting electric noise, which can be frustrating and affect the overall performance of the console. We will delve into the possible causes, troubleshooting steps, and potential solutions to help you resolve this issue.

Before we dive into the troubleshooting process, it's essential to understand how electroluminescent displays work. ELDs use an electric current to excite a phosphor coating, which produces light. This technology is commonly used in displays, such as those found in old mixing consoles, to provide a visual representation of audio levels, settings, and other critical information.

Possible Causes of Electric Noise from ELD

There are several reasons why your Acousta DCA-200's ELD might be emitting electric noise. Some of the possible causes include:

Switch Mode Power Supply (SMPS) Issues: The SMPS is responsible for providing power to the ELD. If the SMPS is malfunctioning or not designed to handle the display's power requirements, it can cause electric noise.
Capacitor Failure: Capacitors are used to filter and regulate the power supply to the ELD. If a capacitor fails, it can cause a range of problems, including electric noise.
Electromagnetic Interference (EMI): EMI can be caused by nearby electronic devices, such as computers, phones, or other audio equipment. This can interfere with the ELD's operation and cause electric noise.
Display Driver Issues: The display driver is responsible for controlling the ELD's operation. If the driver is faulty or not designed to handle the display's power requirements, it can cause electric noise.

To troubleshoot the issue, follow these steps:

Check the Power Supply: Verify that the power supply is functioning correctly and providing the required voltage and current to the ELD.
Inspect the Capacitors: Check the capacitors used in the power supply and ELD circuitry for signs of failure, such as swelling, leakage, or physical damage.
Measure the ELD's Power Requirements: Use a multimeter to measure the ELD's power requirements and compare it to the power supply's output.
Check for EMI: Move the console away from other electronic devices and see if the electric noise persists.
Replace the Display Driver: If the display driver is faulty, replace it with a new one or try to repair it.
Clean the Display: Clean the display and surrounding area to ensure that there are no physical obstructions or debris causing the issue.

Based on the troubleshooting steps, you may need to replace the following components:

SMPS: If the SMPS is malfunctioning, consider replacing it with a new one designed for the ELD's power requirements.
Capacitors: Replace any failed capacitors with new ones of the same value and rating.
Display Driver: Replace the display driver with a new one or try to repair it.
Power Supply: If the power supply is not functioning correctly, consider replacing it with a new one.

Emitted electric noise from the electroluminescent display of a mixing console can be a frustrating issue. By understanding the possible causes and following the troubleshooting steps, you can identify and potentially resolve the problem. Remember to always follow proper safety procedures when working with electrical components, and consider seeking professional help if you're not comfortable with DIY repairs.
